Rubber Lined Parts
Whether a new build or a re-line, our designers and fabricators will look over your lining application. From there they will construct or rebuild your rubber-lined parts to OEM specs. We can beef up certain wear areas and apply the right rubber to ensure a long wear life for your application.
Available in gum rubber, SBR, neoprene (highest heat resistance up to 250°F), or chlorobutyl. All linings are vulcanized in our computer-controlled, large-format autoclave to ensure complete cure.
Typical jobs:
- Chute
- Hopper
- Tubs
- Launder boxes
- Troughs
- Feeders
- Agitator blades
- Mixing propellers
- Flotation parts
- Pulley lagging
- Headers
- Combiners
- Tanks
Great for impact abrasion or corrosive media found in chemical, mineral beneficiation, metallurgical, coal prep, sand, gravel, clay kaolin, limestone preparation, and FGD circuits in coal-fired power plants
- Custom rubber selection and lay-up thickness to improve your known wear patterns
- Improve the OEM design based on your experience and our know-how
- Factory repair ensures the best adhesion and rubber cure
- Reduce in-plant noise
Elastomer Properties
*Association for Rubber Products Manufactures*
Physical Properties
- Durometer range: 35-65
- Tensile Strength, PSI: 4000+
- Elongation %: ≤700
- Tear Resistance: Excellent
- Abrasion Resistance: Excellent
- Flexibility: Excellent
- Rebound(cold): Excellent
- Rebound(hot): Excellent
Chemical Properties
- UV Aging: Poor
- Ozone Resistance: Poor
- Acid Resistance (dilute): Fair
- Oil & Gasoline: Poor
- Aliphatic Hydrocarbons: Poor
- Aromatic Hydrocarbons: Poor
- Max Operating Temp °F: 180°
Physical Properties
- Durometer range: 50-60
- Tensile Strength, PSI: 3000
- Elongation %: 500
- Tear Resistance: Good
- Abrasion Resistance: Excellent
- Flexibility: Good
- Rebound(cold): Fair
- Rebound(hot): Good
Chemical Properties
- UV Aging: Poor
- Ozone Resistance: Poor
- Acid Resistance (dilute): Fair
- Oil & Gasoline: Poor
- Aliphatic Hydrocarbons: Poor
- Aromatic Hydrocarbons: Poor
- Max Operating Temp °F: 180°
Physical Properties
- Durometer range: 55-65
- Tensile Strength, PSI: 3000
- Elongation %: ≤800
- Tear Resistance: Good
- Abrasion Resistance: Good
- Flexibility: Good
- Rebound(cold): Very Good
- Rebound(hot): Very Good
Chemical Properties
- UV Aging: Very Good
- Ozone Resistance: Excellent
- Acid Resistance (dilute): Excellent
- Oil & Gasoline: Good
- Aliphatic Hydrocarbons: Good
- Aromatic Hydrocarbons: Poor
- Max Operating Temp °F: 220°
Physical Properties
- Durometer range: 50-60
- Tensile Strength, PSI: 2000
- Elongation %: ≤600
- Tear Resistance: Fair
- Abrasion Resistance: Excellent
- Flexibility: Good
- Rebound(cold): Poor
- Rebound(hot): Good
Chemical Properties
- UV Aging: Very Good
- Ozone Resistance: Excellent
- Acid Resistance (dilute): Excellent
- Oil & Gasoline: Poor
- Aliphatic Hydrocarbons: Poor
- Aromatic Hydrocarbons: Poor
- Max Operating Temp °F: 250°
Physical Properties
- Durometer range: 80-85
- Tensile Strength, PSI: 4500
- Elongation %: ≤550
- Tear Resistance: Fair
- Abrasion Resistance: Fine feed
- Flexibility: Poor
- Rebound(cold): Fair
- Rebound(hot): Poor
Chemical Properties
- UV Aging: Very Good
- Ozone Resistance: Excellent
- Acid Resistance (dilute): Good
- Oil & Gasoline: Good
- Aliphatic Hydrocarbons: Good
- Aromatic Hydrocarbons: Poor
- Max Operating Temp °F: 160°
